ST1008 SMART SENSOR

Buy now ST1008 SMART SENSOR at best price in Pakistan 2023.

Order now: https://smartsensor.pk/st1008-smart-sensor

Product introduction:

T1008 multi-channel temperature tester can collect multi-channel temperature data at the same time, super-up and down-super alarm and communication transmission, compatible with a variety of temperature sensors, fast response, stable data, and has a burnout detection function. Moreover, it is controlled by a high-performance 32-bit ARM microprocessor. The instrument uses true-color TFT-LCD, full Chinese operation interface, keyboard and touch screen operation, high-precision measurement and ease of use to bring users a new testing experience. The instrument supports large-capacity USB memory.

    The whole series of instruments are equipped with USB-HID interface as standard. The computer remote control commands open to users are compatible with SCPI (Standard Command for Programmable Instrument standard command set), and users can write computer software independently to efficiently complete remote control and data acquisition functions. .

Technical Parameters

Connection to test side

 With 8 sets of input terminals

Graduation number

Thermocouple: J, K, T, E, S, N, B, R

Test Range

-200°C~1800°C (change according to different sensor models)

basic accuracy

0.2%+1

resolution

0.1°C

number of channels

2 way/4 way/8 way

FUNCTION

have

Sampling speed setting

Default medium speed (slow, medium, fast)

℃/℉ temperature unit conversion

have

Comparator settings

Upper/lower limit alarm, each channel can set the upper and lower limits separately

Quick Response Settings

Supports opening and closing

Other functions

language settings

Chinese/English switch

USB remote control

Using USB-HID protocol, ASVII transmission

Backlight brightness adjustment

4 gear display, 20%/40%/80%/100%

Accessory interface

U disk interface/MICROSD card slot

save settings

Storage method setting (U disk/micro SD card)

Product Weight

500g

Product Size

194*91*34.5mm
